- 1 – 49998
US $0.42
- 49999 – 99998
US $0.37
- >=99999
US $0.32
- Place of Origin:
-
Zhejiang, China (Mainland)
- Brand Name:
-
OSolar
- Model Number:
-
OSM60-156P-270W
- Material:
-
Polycrystalline Silicon
- Size:
-
1650*992*40mm
- Number of Cells:
-
60pcs
- Max. Power:
-
270W
- Solar Cell:
-
4 Busbar Polycrystalline 156*156mm
- Cell Orientation:
-
60 cells (6*10)
- Weight:
-
18.6kG (41lb)
- Glass:
-
3.2mm (0.13inches), High Transmission, AR Coated Tempered Glass
- Frame:
-
Silver & Black Anodized Alunniu Alloy
- Backsheet:
-
Silver & Black
- Junction Box:
-
IP65 or IP67 Rated
- Cables:
-
Photovoltaic Technology cable 4.0mm2, length 900mm
- Connector:
-
MC4 Compatible Connector
- Warranty:
-
12 Years Product Warranty and 25 Years Linear Power Output Warranty
- Packaging Details
- Well protected carton with pallet for poly pv 24v 250w 260w 265w 270w 280w 290w 300w solar panel
- Delivery Time
- 10 working days after payment
Osolar solar power panel factory poly pv 24v 250w 260w 265w 270w 280w 290w 300w solar panel
DATA (STC) | ||||||||||
ELECTRICAL DATA (STC) | ||||||||||
Peak Power Watt-PMAX (Wp) | 230 | 235 | 240 | 245 | 250 | 255 | 260 | 265 | 270 | 275 |
Power Output Tolerance-PMAX (W) | ±3% | |||||||||
Maximum Power Voltage-VMPP (V) | 31.18 | 31.30 | 31.42 | 31.52 | 31.70 | 31.90 | 32.10 | 32.40 | 32.70 | 32.95 |
Maximum Power Current-IMPP (A) | 7.55 | 7.63 | 7.72 | 7.83 | 7.92 | 8.00 | 8.10 | 8.18 | 8.28 | 8.37 |
Open Circuit Voltage-VOC(V) | 37.60 | 37.71 | 37.82 | 37.90 | 38.00 | 38.10 | 38.20 | 38.30 | 38.40 | 38.49 |
Short Circuit Current-ISC(A) | 8.20 | 8.27 | 8.35 | 8.46 | 8.55 | 8.60 | 8.67 | 8.73 | 8.82 | 8.90 |
Module Efficiency (%) | 14.05% | 14.36% | 14.66% | 14.97% | 15.27% | 15.58% | 15.88% | 16.19% | 16.50% | 16.80% |
STC:Irradiance 1000W/m2, Cell Temperature 25.C, Air Mass AM 1.5 | ||||||||||
TEMPERATURE RATINGS | MAXIMUM RATINGS | |||||||||
Nominal Operating Cell Temperature (NOCT) | 44.C(±2℃) | Operational Temperature | -40~+85℃ | |||||||
Temperature Coefficient of PMAX | -0.39%/℃ | Maximum Syste Voltage | 1000V DC (IEC) | |||||||
Temperature Coefficient of VOC | -0.29%/℃ | Max Series Fuse Rating | 15A | |||||||
Temperature Coefficient of ISC | 0.05%/℃ |



1.Can I know how to choose the models?
Please read the DATA SHEET in the page or download our products Catalog of each products,Of course it is ok for you, please inquire us directly for any techique questions of our products.
2.If you can accept my own payment ways?
If your order less than 1 KW, Only accept 100%TT or Paypal(and you need to pay the transfer fee);If the order bigger than 1 MW,it is up to you on any payment terms;
3.Are you factory or trading company?
We are a professional factory and manufacturer with more than 10 years(but just open Alibaba Platform 1 year);
4.Where is your factory located?How can I visit there?
Shanghai Hong International Trading Co.,Ltd(trading firm with headquaters in Shanghai)
Add:24F,Block A,No.18 Caoxi North Road,Xuhui District,Shanghai,China.
Jiaxing Osolar PV Co.,Ltd(factory in Zhejiang)
Add:No.1555,Xi Ping Si Road,Pinghu Economic Development Zone,Zhengjiang,China.
Suzhou Solarwii Micro Grid Technology Co.,Ltd(factory in Suzhou)
Add:Rm 405,Nan Gong Yuan Building,No.399 Linquan Street,Suzhou Industrial Park,Suzhou,China.
Changzhou Allstar Energy Technology Co., Ltd(factory in Jiangsu)
Add: Zhiqian Town, Jintan Changzhou, Jiangsu, China.
5.How does your factory do regarding quality control?
Quality is priority.We always attach great importance to quality controlling from the begining to the end(including Solar Cell Testing,Solar Cell Sorting,Automatic String,Electrical Performance Testing),all products are fully approved and certificated by globally recognized authority,including IEC/TUV/CE/C.
